Blood Gas Analyzer
M114 Blood Gas Analyzer
- Brand: Medshine
- Model No.: M114
- Certificate: CE,ISO
- Warranty:18 months
- Product description: When a critically ill patient is suffering from a respiratory or metabolic disorder, arterial blood gas analysis is central to evaluate his status, make the appropriate diagnostic decisions and monito
M114 Blood Gas Analyzer
Specification
Sample Type
Whole blood, Serum, Plasma, Dialysate, CSF
Model name & test items
M114 ( pH/pCO2/pO2/K+/Na+/CI-/Ca++/Hct )
M114 A(pH/ pCO2/ pO2 /Hct )
M114 B ( pH/pCO2/pO2/K+/Na+/CI-/Hct )
M114 E ( pH/pCO2/pO2/K+/Na+/CI-/Ca++/Hct /Glu/Lac)
Measured Parameters
|
Analyte |
Measuring range |
Unit |
|
pH(CH) |
6.000-9.000 |
|
|
pCO2 |
1.607-26.67 |
kpa |
|
8.0-200.0 |
mmHg |
|
|
pO2 |
0-106.7 |
kpa |
|
0-800.0 |
mmHg |
|
|
K |
0.5-15.0 |
mmol/L |
|
Na+ |
20.0-200.0 |
mmol/L |
|
CI- |
20.0-200.0 |
mmol/L |
|
Ca++ |
0.3-5.0 |
mmol/L |
|
Hct |
12.0-65.0 |
% |
|
B.P. |
500-800 |
mmHg |
|
Glucose |
1.1-66.7 |
Mmol/L |
|
Lactate |
0.4-30.0 |
Mmol/L |
Main Characteristics
Ø Multi-combination parameters
Ø Self-made maintenance free electrodes
Ø Both for syringes & capillary
Ø 35UL for capillary, 95UL for whole blood
Ø 1 min from the aspiration to result
Ø Long-lasting fluid system
Ø All-in-one design calibrate cartridge
Ø Cartridge expiration alarm & residue
Ø Preheats reagents & sample
Ø Optional Auto QC cartridge with H/M/L level
Ø Data storage >5,000
Ø Colorful touch screen with high resolution
Ø Friendly operation interface
Ø Infrared human-detector
Ø Rich data management interface
Ø Battery backup
Ø Build-in thermal printer
Ø Convenient bar-code system management
Ø Economic cost per test
Working environment
Working temperature：15℃~30℃
Storage environment：5℃~45℃
Power supply：100-240V~±10&，50/60±1Hz
Power：150VA
Dimension (Length*width*Height) 420mm×623mm×410mm
Weight 25KG
